Deye 16kW Hybrid Inverter (Single Phase)
High-Power, Smart Solar Inverter for Residential and Commercial Systems
The Deye 16kW Single Phase Hybrid Inverter is a premium solar energy solution engineered for maximum performance, flexibility, and energy independence. Designed for high-demand residential or small commercial solar systems, this hybrid inverter efficiently manages power from solar panels, the electrical grid, and batteries—ensuring reliable energy 24/7.
Important Note: In backup (off-grid) mode, the inverter supplies up to 13kW output power.
Key Features of the Deye 16kW Hybrid Inverter:
High Output Power: Delivers 16,000W for on-grid use, ideal for large homes or light commercial buildings
Smart Hybrid Technology: Supports grid-tied, off-grid, and backup modes with seamless automatic switching
Battery Compatibility: Works with lithium-ion and lead-acid batteries; supports multiple battery systems in parallel
Efficient MPPT Solar Charging: Three Maximum Power Point Tracking (MPPT) inputs ensure maximum solar energy harvesting
High Charge/Discharge Capacity: 290A for fast, efficient battery charging and discharging
Remote Monitoring: Built-in WiFi and GPRS modules for real-time performance tracking via mobile app or web portal
Generator Support: Compatible with diesel generators for extended backup options
Scalable System: Supports parallel connection of up to 16 inverters for larger solar installations
Easy Integration: Can be used in both new solar installations and retrofit upgrades of existing PV systems
Durable Design: IP65 rated for outdoor use, with quiet operation (<30dB) and smart cooling technology
Ideal Applications:
Residential solar energy systems with high energy consumption
Commercial solar systems for small offices, retail, farms, or workshops
Backup power for areas with unstable or limited grid access
Upgrading existing DC or AC-coupled inverters in PV systems
Off-grid solar projects requiring reliable battery and generator integration
Technical Specifications:
| Specification | Details |
|---|---|
| Model | SUN-16K-SG01LP1-EU |
| Rated Power | 16kW (13kW in backup mode) |
| Max PV Input Power | 20,800W |
| Max DC Voltage | 500V |
| MPPT Range | 150–425V |
| MPPT Inputs | 3 MPPTs / 2 Strings per MPPT |
| Max PV Input Current | 26A + 26A + 26A |
| Max PV Short Circuit Current | 44A + 44A + 44A |
| Battery Voltage Range | 40–60V |
| Max Charging/Discharging Current | 290A |
| Supported Battery Types | Lithium-ion, LiFePO4, Lead-acid |
| Communication Ports | RS485, CAN, WiFi/GPRS |
| Cooling | Intelligent fan cooling |
| Noise Level | Less than 30 dB |
| Operating Temperature | -45°C to +60°C |
| Dimensions (W x H x D) | 464 × 798.4 × 300 mm |
| Weight | 51.5 kg |
| Enclosure Protection | IP65 (dustproof and water-resistant) |
