Models

SUN-120K-G01P3
-EU-AM8

SUN-125K-G01P3
-EU-AM8

SUN-130K-G01P3
-EU-AM8

SUN-135K-G01P3
-EU-AM8

SUN-136K-G01P3
-EU-AM8

Input Side

Max. DC Input Power (kW)

180

187.5

195

202.5

204

Max. DC Input Voltage(V)

1100

Start-up DC Input Voltage (V)

250

MPPT Operating Range (V)

200-1000

Max. DC Input Current (A)

40+40+40+40+40+40+40+40

Max. Short Circuit Current (A)

60+60+60+60+60+60+60+60

No. of MPP Trackers

8

No.of Strings per MPP Tracker

4+4+4+4+4+4+4+4

Output Side

Rated Output Power (kW)

120

125

130

135

136

Max. Active Power (kW)

132

135

135

135

136

Nominal Output Voltage / Range (V)

3L/N/PE 220/380V, 230/400V

Rated Grid Frequency (Hz)

50 / 60 (Optional)

Operating Phase

Three Phase

Rated AC Grid Output Current (A)

181.9/174

189.4/181.2

204.6/195.7

206.1/197.2

200/191.4

204.6/195.7

204.6/195.7

204.6/195.7

206.1/197.2

Output Power Factor

>0.99

Grid Current THD

<3%

DC Injection Current (mA)

<0.5%

Grid Frequency Range

45~55 or 55~65 (Optional)

Efficiency

Max. Efficiency

98.8%

Euro Efficiency

98.3%

MPPT Efficiency

>99%

Protection

DC Reverse-Polarity Protection

Yes

AC Short Circuit Protection

Yes

AC Output Overcurrent Protection

Yes

Output Overvoltage Protection

Yes

Insulation Resistance Protection

Yes

Ground Fault Monitoring

Yes

Anti-islanding Protection

Yes

Temperature Protection

Yes

Integrated DC Switch

Yes

Remote Software Upload

Yes

Remote Change of Operating Parameters

Yes

Surge Protection

DC Type II / AC Type II

General Data

Cabinet Size (WxHxD mm)

1006×516×325.5 (Excluding Connectors and Brackets)

Weight (kg)

103

Topology

Transformless

Internal Consumption

<1W (Night)

Running Temperature

-25-60℃, >45℃ Derating

Ingress Protection

IP65

Noise Emission (Typical)

≤65 dB

Cooling Concept

Smart Cooling

Permissible Altitude (m)

4000

Designed Lifetime

>20 Years

Operating Surroundings Humidity

0-100%

Features

DC Connection

MC-4 Mateable

AC Connection

IP65 Rated Plug

Display

Interface

RS485/RS232/Wifi/LAN
